Best Stone Cutting Machine

Linhai Zhongli Machinery Manufacturing Co., Ltd. is one of the most reliable manufacturers and suppliers of best stone cutting machine in China. Welcome to wholesale durable best stone cutting machine in stock here and get quotation from our factory. Quality products and reasonable price are available.





Model	4+1 Axis CNC bridge saw	5+1 Axis CNC bridge saw	Unit
Worktable size	L3500*W2000	L3500*W2000	mm
Maximum cutting	L3500*W2000*H90	L3500*W2000*H90	mm
Maximum chamfering	L3500*W2000*H60	L3500*W2000*H60	mm
Blade diameter	350-425	350-425	mm
Main motor power	15	22 (permanet magnet motor with frequency)	kw
Router power	5.5	5.5	kw
Control center	industry computer with CNC	industry computer with CNC
Controller brand	"Cut Cam" CNC System	"Cut Cam" CNC System or ESA system from Italy
Driving motor	Servo motor	Servo motor
Router max speed	24000	24000	RPM
Total power	28	35	kw
Suction cup lifting weight	200	200	kg
Head rotate	0°-360°	0°-360°
Head tilt	0°and 45°	0°-90°
Cylinders	5	5	group
Dimensions	L5750*W3260*H3500	L5750*W3260*H3500	mm
Water consumption	2	2	m³/h
Total weight	5.4	5.4	t
Main part delivered size	5750x2200x2500	5750x2200x2500	mm
Machine-delivered method	Main part delivered as a whole (HQ container)	Main part delivered as a whole (HQ container)





Option: (System)   1. Self-developed CNC System with "Cut Cam"software 2. ESA System from Italy

Option: Chassis be hot-dip galvanized

Option: Add front sliding doors

Option: Worktable be faced with plastic plate and rubber





Features:



1: The machine is a conjoined structure; it takes up less space and is easy to install and move.



2: This machine has excellent four-side chamfering function and an excellent chamfering range 3500x2000mm





​3: With an industrial computer and a 17" color touch-screen.





Option: own CNC system or ESA system from Italy

4: Use a camera to locate the position of the plate and display it in the cutting procedure.



5: The (5+1)A type with a 22-KW permanent magnet motor can be cut along with the thickness of the cutting plate, automatically adjusting the output power, strength, and power-saving environmental protection.

6: An automatic tool setting gauge is equipped that automatically checks the blade.



7. The system has a built-in library of conventional-shaped drawings and also supports DXF format imports from a designer or a countertop measuring gauge.







































8: The worktable can be flipped up to 85°.

9: A group of rotating cylinders on the side of the work table will automatically press the plate when the milling cutter works and automatically withdraw after the milling cutter works.





10: Option: the machine chassis could be hot-dip galvanized, and the worktable could be faced with plastic plates and rubber.





11: Option: front sliding door



Application Picture and Video















Shipment

Factory





Honour

The 5-Axis CNC Bridge Saw is ideal for cutting through even the hardest materials, including granite, quartz, and marble, with ease and precision. Its state-of-the-art cutting blades make clean and precise cuts, ensuring that your final product meets the highest standards of quality.



In addition to its outstanding cutting capabilities, this machine also offers advanced polishing and chamfering features, which allow you to create smooth and polished edges that are perfect for your final product. These features are ideal for businesses that are looking to create high-end products that require a professional finish.



Our 5-Axis CNC Bridge Saw is built to last, with a robust construction that can withstand years of heavy use. It is also easy to use, with a user-friendly interface that allows you to operate the machine with ease and precision. Whether you're just starting out in the industry or are looking to upgrade your existing equipment, this powerful machine is the perfect choice for all your stone-cutting needs.



So, if you're looking for the best stone cutting machine on the market, look no further than our 5-Axis CNC Bridge Saw. With its advanced automatic capabilities, precision cutting, and advanced polishing and chamfering features, this machine is the perfect solution for all your stone-cutting needs. So why wait? Order your 5-Axis CNC Bridge Saw today and experience the best in stone cutting technology!





La sierra de puente CNC de 5 ejes es ideal para cortar incluso los materiales más duros, incluidos granito, cuarzo y mármol, con facilidad y precisión. Sus hojas de corte de última generación realizan cortes limpios y precisos, asegurando que su producto final cumpla con los más altos estándares de calidad.

Además de sus excelentes capacidades de corte, esta máquina también ofrece funciones avanzadas de pulido y biselado, que le permiten crear bordes lisos y pulidos que son perfectos para su producto final. Estas características son ideales para empresas que buscan crear productos de alta gama que requieren un acabado profesional.

Nuestra sierra de puente CNC de 5 ejes está diseñada para durar, con una construcción robusta que puede soportar años de uso intensivo. También es fácil de usar, con una interfaz fácil de usar que le permite operar la máquina con facilidad y precisión. Ya sea que recién esté comenzando en la industria o esté buscando actualizar su equipo actual, esta potente máquina es la elección perfecta para todas sus necesidades de corte de piedra.

Entonces, si está buscando la mejor máquina cortadora de piedra del mercado, no busque más que nuestra sierra de puente CNC de 5 ejes. Con sus capacidades automáticas avanzadas, corte de precisión y funciones avanzadas de pulido y biselado, esta máquina es la solución perfecta para todas sus necesidades de corte de piedra. Entonces, ¿por qué esperar? ¡Ordene hoy su sierra de puente CNC de 5 ejes y experimente lo mejor en tecnología de corte de piedra!
