Cnc Stone Cutting Machine Price
Linhai Zhongli Machinery Manufacturing Co., Ltd. is one of the most reliable manufacturers and suppliers of cnc stone cutting machine price in China. Welcome to wholesale durable cnc stone cutting machine price in stock here and get quotation from our factory. Quality products and reasonable price are available.
Products Description
|
Model |
4+1 Axis CNC bridge saw |
5+1 Axis CNC bridge saw |
Unit |
|
Worktable size |
L3500*W2000 |
L3500*W2000 |
mm |
|
Maximum cutting |
L3500*W2000*H90 |
L3500*W2000*H90 |
mm |
|
Maximum chamfering |
L3500*W2000*H60 |
L3500*W2000*H60 |
mm |
|
Blade diameter |
350-425 |
350-425 |
mm |
|
Main motor power |
15 |
22 (permanet magnet motor with frequency) |
kw |
|
Router power |
5.5 |
5.5 |
kw |
|
Control center |
industry computer with CNC |
industry computer with CNC |
|
|
Controller brand |
"Cut Cam" CNC System |
"Cut Cam" CNC System or ESA system from Italy |
|
|
Driving motor |
Servo motor |
Servo motor |
|
|
Router max speed |
24000 |
24000 |
RPM |
|
Total power |
28 |
35 |
kw |
|
Suction cup lifting weight |
200 |
200 |
kg |
|
Head rotate |
0°-360° |
0°-360° |
|
|
Head tilt |
0°and 45° |
0°-90° |
|
|
Cylinders |
5 |
5 |
group |
|
Dimensions |
L5750*W4150*H3500 | L5750*W4150*H3500 |
mm |
|
Water consumption |
2 |
2 |
m³/h |
|
Total weight |
5.4 |
5.4 |
t |
|
Main part delivered size |
5750x2200x2600 | 5750x2200x2600 |
mm |
|
Machine-delivered method |
Main part delivered as a whole (HQ container) |
Main part delivered as a whole (HQ container) |
Add Front Slising Door(Optional):
|
Option: (System)
1. Self-developed CNC System with "Cut Cam"software 2. ESA System from Italy |
Option: Chassis be hot-dip galvanized |
Option: Add front sliding doors |
Option: Worktable be faced with plastic plate and rubber |
Features
1: The machine is a conjoined structure; it takes up less space and is easy to install and move.
2: This machine has excellent four-side chamfering function and an excellent chamfering range 3500x2000mm
3: With an industrial computer and a touch-screen.
Option: CutCam CNC system or ESA system from Italy
4: Use a camera to locate the position of the plate and display it in the cutting procedure.
5: The (5+1)A type with a 22-KW permanent magnet motor can be cut along with the thickness of the cutting plate, automatically adjusting the output power, strength, and power-saving environmental protection.
6: An automatic tool setting gauge is equipped that automatically checks the blade.
7. The system has a built-in library of conventional-shaped drawings and also supports DXF format imports from a designer or a countertop measuring gauge.
8: The worktable can be flipped up to 85°.
9: A group of rotating cylinders on the side of the work table will automatically press the plate when the milling cutter works and automatically withdraw after the milling cutter works.
10: Option: the machine chassis could be hot-dip galvanized, and the worktable could be faced with plastic plates and rubber.
Application Picture and Video
Shipment
Our Factory &Equipments
CE Certificate
CNC stone cutting machines have revolutionized the stonework industry by introducing advanced technology that increases efficiency, precision, and accuracy. These machines have become increasingly popular across the globe due to their versatility, efficiency, and cost-effectiveness. Here are some of the advantages of CNC stone cutting machine price.
Firstly, CNC stone cutting machines are incredibly versatile and can operate in a wide range of industries, including construction, architecture, interior design, and sculpture art. These machines can be used to cut a variety of natural stones such as marble, granite, limestone, and sandstone. They can also cut other materials such as glass, ceramics, and metals.
Secondly, CNC stone cutting machines are highly accurate and precise, ensuring that every cut is precise and uniform. The advanced technology used in CNC machines enables them to cut intricate designs and shapes with ease, making them ideal for architectural decorations, sculptures, and other intricate designs.
Thirdly, CNC stone cutting machines are highly efficient, which means that they can save on time and labor costs. They can also reduce material wastage and minimize errors, resulting in substantial savings on material costs.
Fourthly, CNC stone cutting machines are user-friendly and easy to operate. With the help of software programs, cutting designs can be uploaded and transferred to the machine, reducing the human error, and the need for specialized skills and training. This feature makes it easier for manufacturers to produce large quantities of customized stone products.
Finally, CNC stone cutting machines are cost-effective compared to traditional stone-cutting tools. These machines require minimal maintenance and have a long lifespan, thereby reducing maintenance and repair costs. Moreover, the efficiency and precision of the machine enable manufacturers to produce high-quality products at a lower cost per unit, which can improve their profit margins.
In conclusion, CNC stone cutting machines have revolutionized the stonework industry by introducing technology that enhances efficiency, precision, accuracy, versatility, and cost-effectiveness. These machines enable manufacturers to produce high-quality customized stone products at a lower cost, which can be appealing to customers and help boost business profitability.
